The gabion is made of high corrosion resistance, high strength, ductile low carbon steel wire or PVC coated steel.
The box structure is made of gabion cage.According to ASTM and EN standards,the diameter of the low carbon steelwire used varies depending on the engineering design requirements,Generally between2.0-4.Omm,gabion steel wiretensile strength of not less than 380Mpa,zinc coating weight can reach 300g/m2,stone cage mesh edge diameter isgenerallygreater than the diameter of the cable,
Gabion Basket are wire mesh boxes, containers or baskets filled with rock to prevent soil erosion and to retain/contain soil particles. Flat Gabions, called River, are widely used in river courses where soil erosion is a problem over a large flat or sloped area in need of protection against soil loss or scour. They are used mostly in the civil engineering industry, especially in the construction of roadway drainage structures. Recently however, due to the environmental benefits associated with gabions, they are being used in many various applications and industries.


|
Specification Of Gabion Basket
|
|||||
|
Gabion size
(m)
|
Wire diameter
|
Mesh opening
|
Surface treatment
|
||
|
Mesh wire
(mm)
|
Selvage wire
(mm)
|
Tie wire
(mm)
|
|||
|
2×1×0.5
|
2.0
2.2
2.4
2.7
3.0
|
2.4
2.7
3.0
3.4
3.9
|
1.8
2.0
2.2
|
60 x 80mm
80 x 100mm
80 x 120mm
100 x 120mm
120 x 150mm
|
Galvanized
Galfan
PVC coated
PE coated
|
|
2×1×1.0
|
|||||
|
3×1×0.5
|
|||||
|
3×1×1.0
|
|||||
|
4×1×1.0
|
|||||
|
6×1×1.0
|
|||||
|
2×1×0.3(Mattress)
|
|||||
|
3×1×0.3(Mattress)
|
|||||
|
All sizes can customized according to your request
|
|||||
